DeFelsko Verifcation Standard Coating Thickness Certif Coated Metal Plates S3

Aantal:
v
Toevoegen
PDEF STDS3
DeFelsko Verifcation Standard Coating Thickness Certif Coated Metal Plates S3
Ideaal voor PosiTest G & GM en PosiPen A, B & C
Dikte plaat 1 0
Dikte plaat 2 15 µm
Dikte plaat 3 40 µm
Dikte plaat 4 100 µm
Epoxy op staal
Nauwkeurigheid: +/- 0.43 µm

Certified coated metal plates and polystyrene blocks are ideal for verifying the accuracy and operation of coating thickness gages and are an important component in fulfilling both ISO and in-house quality control requirements.

Many organizations require verification of gage accuracy at the test site each time a coating thickness gage is put into service and at frequent intervals during use. Ideal for this purpose, DeFelsko certified coating thickness standards have measured values traceable to a National Metrology Institution.

Used to verify the accuracy and operation of any Type 1 (mechanical) and Type 2 (electronic) magnetic, eddy-current or ultrasonic coating thickness gage
Ideal for use in the calibration lab, in the field or on the factory floor
Standards with steel or aluminum substrates consist of 4 plates mounted in a protective binder
Polystyrene thickness standards consist of 4 blocks supplied in a rugged acrylic storage box
Individually serialized for traceability to NIST or PTB - includes a Certificate of Calibration
Certified and labeled in both Metric and Imperial units
Zero Plates available for both Certified Coated Metal Plates and Certified Polystyrene Blocks.
